16K Lippert Triple Axle Dual TK Trailer Kit — 48,000 lb | 74/42 (3-4 Week Processing)

Triple axle running gear in one package: three 16K Lippert electric brake axles, three hanger kits, plus twelve tire & wheel assemblies.

Specifications:

• Capacity: 48,000 lb (3 x 16,000 lb axles)
• Axles: 16K Lippert, electric brake, sprung
• Hubface/Spring Center: 74/42 (3-4 Week Processing)
• Bolt pattern: 8x275mm
• Lubrication: Oil bath
• Tires & wheels: (12) 17.5" 18 ply radial, ST 215/75R17.5, silver dual
• ABS: Not ABS compatible

What’s Included:

• (3) 16k Lippert Electric Brake Trailer Axle (Sprung) - 74/42 - 8x275mm
• (2) Slipper Tandem Suspension Equalizer Kit for 10k- 15k axles
• (1) Slipper Single Axle Suspension/Hanger Kit for 10k-15k axles
• (12) 17.5" 18 ply Radial Trailer Tire & Wheel - ST 215/75R17.5 (Silver Dual) - 8x275mm

How to Measure: Hubface is measured from one hub face (where the studs come out) to the hub face on the opposite side. Spring Center is measured from the center of one spring seat to the center of the opposite spring seat.

Key Benefits:

• Pre-packaged kit to ensure proper fitment of running gear
• OEM grade trailer axles and suspension
• Axles come fully assembled
• Underslung: spring seats welded on the bottom for a lower ride height
• High strength straight steel axle tube construction
• Oil bath lubrication
• OEM grade tires designed for highway use

Ideal For:

• Car hauler, lawn & landscape, and flatbed trailers
• Lowboy, gooseneck, and dump trailers

Why Buy from The Trailer Parts Outlet?

• Quality trailer parts at affordable prices
• Fast shipping — order today, ships tomorrow
• Bulk & wholesale pricing available
• Dedicated expert support

Have questions? Call or message us at (936) 289-3191.

16K Electric Brake Triple Axle TK Trailer Kit — Dual — 48K capacity | Axles, Suspension, Tires & Wheels

Complete triple running gear in one package: three 16,000 lb electric brake axles, matched slipper suspension, and eight 17.5 inch dual radial tire and wheel assemblies. 48,000 lb combined capacity.

Axle Specifications:

• Load rating: 16,000 lbs (16K)
• Axle type: Electric Brake (Oil Bath)
• Brake size: 12¼″ × 5″ electric drum
• Tube diameter: 5″ straight steel axle tube
• Hubface/Spring Center: Custom, enter your measurements
• Bolt pattern: 8 on 275mm (8x275mm)
• Stud size: 22mm
• Spring mount:Underslung or Overslung, choose your configuration
• Lubrication: Oil Bath
• Compatibility: Fits 15K–16K Dexter, TK, and Texas Pride axles (not compatible with Rockwell)
• ABS: Not compatible with ABS systems

How to Measure: Hubface is measured from one hub face (where the studs come out) to the hub face on the opposite side. Spring Center is measured from the center of one spring seat to the center of the opposite spring seat.

What’s Included:

• (3) Fully Assembled 16k Lippert Electric Brake Oil Bath Axles — Custom, enter your measurements — 8x275mm
• (6) 8k 30″ x 3″ 6-Leaf HD Slipper Springs
• (3) 16k U-Bolt Kits (3/4″, 5″ tube)
• (1) Slipper Triple Hanger Kit (16k)
• (12) 17.5" 215/75R17.5 18 Ply 8x275mm Dual Radial TWA (Tire Wheel Assemblies) — Silver/Gray Finish

Key Benefits:

• Matched triple running gear — no cross-referencing parts
• 5″ steel tubes — 48,000 lb combined capacity

Ideal For:

• Gooseneck & lowboy trailers
• Flatbed & car hauler trailers
• Dump & equipment haulers
• Commercial & fleet builds

Why Buy from The Trailer Parts Outlet?

• This Axle is proudly manufactured in the U.S.A.
• Custom builds to your exact measurements
• Bulk & wholesale options available
• Financing options
• Dedicated expert support

Have questions? Call or message us at (936) 289-3191 — we’re here to help you find the perfect axle for your trailer build or repair. Order your 16K Triple Axle TK Trailer Kit today and get back on the road with confidence!
