16THF - 16'x8' Tiny House Trailer Plans

  • DIY Trailer Plan - 16THF - Tiny House Trailer Plans
  • 16'x8' Tiny House Trailer Blueprint
  • 16THF - 16'x8' Tiny House Trailer Plans - Additional View
1 2

16THF - 16'x8' Tiny House Trailer Plans

16THF - 16'x8' Tiny House Trailer Plans

SKU : MP16THFPAPER

Online price only

$129.99

Online price only

SAVE 0% (833) 910-3416
4.2
Rated 4.2 out of 5 stars
59 Reviews
Shipping: Calculated at Checkout | Product Wt. 1.0 lb
Plan Type:
Kit Option:
Tax Exempt? Enter info in cart when you're done shopping.
View full details
  • Product Information
  • Reviews

16THF 16'x8' Tiny House Trailer Plans — Paper

Engineer-approved master plan for a 16' x 8' tiny house trailer.

Specifications:

  • Bed size: 16' long x 8' wide
  • Gross capacity: 7,000 lb or 10,400 lb
  • Empty weight: 1,330 lbs
  • Empty tongue weight: 190 lbs
  • Frame: Rectangular & square tubing & angle
  • Deck: Platform for tiny house construction
  • Plan format: Paper

What’s Included:

  • (1) 16THF - 16'x8' Tiny House Trailer Plans

Not included: Steel frame/tubing, plywood, or flooring

Key Benefits:

  • Engineer approved & stamped full sized 24" x 36" blueprints
  • Detailed cut list with full bill of materials & welding tips

Ideal For:

  • High school shop & ag classes
  • Industry
  • Do-it-yourselfers
