8000 lb TK Triple Axle Kit - 24K Capacity (Axle Series) 9/16" Studs

8000 lb TK Triple Axle Kit - 24K Capacity (Axle Series) 9/16" Studs

SKU : 08THDAKTTK7556916865

Online price only

$2,619.99

Online price only

SAVE 0% (833) 910-3416
Shipping: Calculated at Checkout | Product Wt. 945.0 lb
Hubface/Spring Center (Frame Width):
Tax Exempt? Enter info in cart when you're done shopping.
View full details
  • Product Information
  • How To
  • Reviews

True 8K Triple Axle Kit — 24K capacity | Axles with Suspension

Complete triple running gear without tires: three 8,000 lb electric brake axles. Matched slipper suspension included. 24,000 lb combined capacity.

Axle Specifications:

  • Load rating: 8,000 lbs (8K)
  • Axle type: Electric Brake
  • Brake size: 12¼″ × 3⅜″ electric drum
  • Tube diameter: 3.5″ extra-heavy straight axle tube
  • Hubface/Spring Center: 75/56
  • Bolt pattern: 8x6.5
  • Stud size: 9/16″
  • Spring mount: Underslung (lower ride height)
  • Compatibility: Direct replacement for Dexter, Rockwell American, Lippert, Hayes, and AL-KO axles
  • ABS: Not compatible with ABS systems

How to Measure: Hubface is measured from one hub face (where the studs come out) to the hub face on the opposite side. Spring Center is measured from the center of one spring seat to the center of the opposite spring seat.

What’s Included:

  • (3) Fully Assembled 8k True TK Electric Brake Axles — 75/56 — 8x6.5
  • (6) 4k 29 1/2" x 2" 6-Leaf HD Slipper Springs
  • (3) 8k U-Bolt Kits (9/16″)
  • (1) Slipper Triple Hanger Kit (5.2k–8k)

Key Benefits:

  • Fully assembled & packed with high-temp axle grease — ready for fast installation
  • 3.5″ extra-heavy steel tube — optimal weight handling and a smoother highway experience
  • EZ-Lube design — grease the axle via zerk fitting without removing the hub
  • Upgraded brakes & bearing — 12¼″ × 3⅜″ drums and an upgraded 02475 outer bearing for more stopping power and axle life
  • Pre-Packaged Fitment — Matched components, no cross-referencing parts

Ideal For:

  • Commercial & fleet trailers
  • Equipment & flatbed haulers
  • Dump & lowboy trailers
  • Car hauler & cargo builds

Why Buy from The Trailer Parts Outlet?

  • This Axle is proudly manufactured in the U.S.A.
  • Fast shipping — order today, ships tomorrow
  • Bulk & wholesale options available
  • Financing options
  • Dedicated expert support

Have questions? Call or message us at (936) 289-3191 — we’re here to help you find the perfect axle for your trailer build or repair. Order your True 8K Triple Axle Kit today and get back on the road with confidence!
